Description

Manholes – Telecom Chambers

Bending and Pulling device for manhole steps and traction anchors in telecom chambers

D2AE testing box

for flexural and tear-off tests on manhole steps and pulling anchors in telecom chambers..

Standards :

Telecom Chambers
 NFP 98-050-1

Pipes – Manholes : Steps for manholes rings
 : NF EN 13101

Fixed steps for Manhole Pipes
 : NF EN 14396

Complete testing box for flexural and pulling tests on manhole steps, and tear-off test on pulling anchors in telecom chambers
.

The D2AE testing box is comprising of a sturdy aluminium casing (IP 65), comprising either the testing jack for manhole steps, or the testing jack for pulling rings, or both jacks
.

It also contains the hydraulic circuitry, with protection and safety valves, and one or two Class 1 digital manometers
.

Flexural jack for steps :

Load 540 daN

Stroke 30 mm

Tear-off jack for pulling anchors
:

Load 50 kn

Stroke 22 mm

Hydraulic pump :

Class 1 Digital displays :

Adjustable testing stick for flexural test
 :
